PVC Hot-cut pelletizing line

PVC Hot-cut pelletizing line

PVC Hot-cut pelletizing line
PVC Hot-cut pelletizing linePVC Hot-cut pelletizing line
CategoriesPlastic Pelletizing&Granulating System
AlbumView larger image
BrandFOSITA
ModelFST-150/250/400/800
Power22-110kw
DimensionCapacity
Weight3000kg
CertificatonCE
Warranty1 year
After-sales serviceField installation, commissioning and training
Colorcustomized
ApplicaitonGranules production
Factory location2 hours from Shanghai
FOB portShanghai
Terms of PaymentL/C, D/A, D/P, Western Union, MoneyGram, T/T
Update Time2019-08-23
Detail Information
Product Description
1.Application of plastic pvc pellets making production machine line
With different designs of screw, this machine can be applied to granulate the recycled material of rigid PVC, soft PVC and waste PVC. It can be stopless in the course of production.
It used pneumatic conversion and strong-wind blowing. At the same time can adjust stainless steel
storage container and can run at high speed for a long time while extrude stably.

2.Features of plastic pvc pellets making production machine line
1,advanced equipment, precise pelletizing and high producing capacity.
2, Conical double-screw extruder, very suitable to process PVC powder with high capacity
3, Pelletizing style: Hot-cutting on mould face, even cutting ensures good shape.
4,Auxiliary machine: Pellets cooling & classifying

3.Process flow of plastic pvc pellets making production machine line
Raw material+ additive → Mixing → Conveying feeding → hopper feeding → Conical twin screw extruder → Hot face cutting → Cyclone separator → Vibration sieve → Blowing system → Storage hopper → Finished product packing
Working Video
Product show
Application
Technical Parameters
Pipe Line Model
Extruder Model
Main Motor Power(kw)
Output(kg/h)
FST-150
SJSZ-55/110
22
100-150
FST-250
SJSZ-65/132
37
200-250
FST-400
SJSZ-80/156
55
350-400
FST-800
SJSZ-92/188
110
650-800
