PVC Door Window Panel Board Profile Extrusion Machine Production Line

PVC Door Window Panel Board Profile Extrusion Machine Production Line

PVC Door Window Panel Board Profile Extrusion Machine Production Line
PVC Door Window Panel Board Profile Extrusion Machine Production LinePVC Door Window Panel Board Profile Extrusion Machine Production LinePVC Door Window Panel Board Profile Extrusion Machine Production LinePVC Door Window Panel Board Profile Extrusion Machine Production LinePVC Door Window Panel Board Profile Extrusion Machine Production Line
CategoriesPlastic Profile Extrusion Machine
BrandFOSITA
ModelFST-240/300/600/900/1200
Automatic GradeFull-automatic
CertificationCE/ISO
After-sales ServiceEngineers available to service machinery overseas
Warranty12 months
Output70-400kg/hr
Max. product size240 mm
Voltage380V 50HZ 3Phase(Customized)
FOB portShanghai
Terms of PaymentL/C, Western Union, T/T
Download
Update TimeOct 10,2024
Detail Information
Specification
Model
SJSZ 51/105
SJSZ 55/110
Screw Dia
51mm
55mm
Main Power
18.5kw
22kw
Central Height
1000mm
1000mm
Main Product
Frame, Door, Batten
Frame, Door, Batten
Barrel Heating and Cooling
Electricity heater, Force cooling by air
Electricity heater, Force cooling by air
Screw Heating and Cooling
Silicon Oil
Silicon Oil
Vacuum Calibration Table
Include vacuum and water pump
Width 240mm
Length 6000mm
Independent operation panel for easy operation
Haul off Cutter
Upper/lower caterpillar driven separately and speed control by inverter
Fast change type pads for easy operation
Install plate is adopts aluminum material
Stacker
Stainless steel 304 as touching material
Discharge driving by air cylinder
Application Use
