New type high speed PP PE PVC corrugated pipe production line
New type high speed PP PE PVC corrugated pipe production line
| Categories | Plastic Pipe Extrusion Machine |
|---|---|
| Brand | FOSITA |
| Model | FST |
| Condition | NEW |
| Plastic Processed | PVC PP PE |
| Screw Design | Single-screw |
| Automatic Grade | Automatic |
| Voltage | 380V 50/60HZ |
| Certification | CE ISO |
| Pipe diameter | 12-50mm |
| Power | 37kw |
| After-sales Service Provided | Engineers available to service machinery overseas |
| FOB port | Shanghai |
| Terms of Payment | L/C, Western Union, T/T |
| Download DOC |  |
| Update Time | Apr 19,2024 |
Detail Information
SPECIFICATION
product advantage
*Gear rack design with good performance of corrugator machine
*Mold block with durable and wear-resistant,also suitable for medical use
*Max.speed can be 40m/min by Fosita design
*All line is equipped with Sienmens PLC
Extruder Model |
SJ45 |
SJ65 |
Motor Power |
18.5kw |
30kw |
Max. Output |
50kg/hr |
120kg/hr |
Diameter Range |
5-16mm |
12-50mm |
Pipe Line Model |
FST-16 |
FST-50 |
Machine Length |
2000mm |
3000mm |
Corrugator Model |
FST-16 |
FST-50 |
Motor Power |
1.5kw |
2.2kw |
Max. Speed |
20m/min |
25m/min |
Diameter Range |
5-16mm |
12-50mm |
Die Block Quantity |
72 pairs |
72 pairs |
Die Block Material |
40Cr |
40Cr |
Winder Model |
FST-16 |
FST-50 |
Disc Quantity |
2 |
2 |
Have encoder |
YES |
YES |
Automatic Level |
Full Automatic |
Full Automatic |
Operation Method |
PLC |
PLC |
Brand |
SIEMENS |
SIEMENS |
Product Details
